The new K2350 with a hook height of 51 m combines the enormous power of the K2300 with the innovative, triple hydraulically telescopic folding jib of the K2500.
Thanks to its solid aluminium rails and a particularly strong folding jib, this powerhouse can transport materials weighing up to 2,000 kg an impressive 26 m. Even with a hook load of three tonnes, it still achieves a lateral reach of 19 m. In single-rope operation, the powerful hoist can lift loads of up to 4,500 kg.
On request, the K2350 is available with a newly developed two-strand operation. This allows it to effortlessly lift up to 9 tonnes to a height of 18 m. Particularly practical: the change from single to double strand operation is automatic, tool-free and simply at the touch of a button on the remote control. As the second crane hook is already integrated into the mast, no additional assembly is required.
Solid support cylinders, double telescopic horizontal support beams and a maximum support width of only 7.34 m make the K2350 the perfect partner even in narrow city centres.
Full panelling
Two-string operation
| Hook load (stand./opt.) | 4.5 /9.0 t |
| Hook height | 50.0 m |
| Total weight1 | ≥ 26 t |
| Outrigger width (min.) | 3.04 m |
| Outrigger width (max.) | 7.34 m |
| Winch capacity | 4,500 kg |
| Boom (4,500 - 500 kg) | 6.65 - 18.80 m |
| Extension 4 (500 kg) | 21.65 m |
| Load | Range | Height |
|---|---|---|
| 4,500 kg | 8.00 m | 32.00 m |
| 3,500 kg | 13.50 m | 29.50 m |
| 3,000 kg | 19.00 m | 25.50 m |
| 2,000 kg | 25.50 m | 16.00 m |
| 1,000 kg | 36.00 m | 14.00 m |
| 500 kg | 42.00 m | 21.80 m |
| 250 kg | 45.00 m | 11.00 m |
| 9t-Funktion | ||
|---|---|---|
| 9,000 kg | 6.00 m | 18.00 m |
| 7,500 kg | 8.00 m | 16.40 m |
| 6,000 kg | 10.00 m | 14.30 m |
| 5,000 kg | 12.00 m | 21.00 m |
